Both HSP and HFP let you make and receive audio calls wirelessly. But HFP was designed for richer scenarios — primarily in-car systems — where the headset needs to do more than just carry audio. HFP adds control features that HSP simply does not have.

HFP defines exactly two roles. Every device in an HFP session must be one of these:

HFP uses two completely separate connections simultaneously — one for control, one for audio. Getting this right is the key to understanding HFP architecture.

All control between the AG and HF happens through AT commands sent over the RFCOMM service level connection. The HF sends commands; the AG sends responses and unsolicited result codes (notifications). The set of AT commands used by HFP is defined in 3GPP TS 27.007.

Key HFP AT Commands Reference

On Linux, HFP is handled by oFono (Open Source Telephony for Linux) working alongside BlueZ. oFono registers itself as the HFP Audio Gateway handler through BlueZ’s D-Bus API. BlueZ manages the Bluetooth connection; oFono handles all the AT command processing and audio routing.

Setup oFono + BlueZ HFP on Ubuntu

# Install oFono
sudo apt install ofono

# Start oFono daemon
sudo systemctl start ofono

# Start BlueZ
sudo systemctl start bluetooth

# Pair your HFP device (phone or headset)
bluetoothctl
[bluetooth]# scan on
[bluetooth]# pair 00:1A:7D:DA:71:11
[bluetooth]# connect 00:1A:7D:DA:71:11
[bluetooth]# trust 00:1A:7D:DA:71:11

# Check oFono sees the HFP modem
dbus-send --system --print-reply \
  --dest=org.ofono / org.ofono.Manager.GetModems

Open a Raw RFCOMM HFP Channel in C

If you want to talk AT commands directly — useful when writing your own HFP Audio Gateway or HF unit — you open an RFCOMM socket and write AT command strings to it. The RFCOMM channel number for HFP is found through SDP service discovery.

/*
 * hfp_at_raw.c — Open RFCOMM channel to HFP device and exchange AT commands
 * Compile: gcc hfp_at_raw.c -o hfp_at_raw -lbluetooth
 * Run:     sudo ./hfp_at_raw
 *
 * NOTE: rfcomm_channel should be discovered via SDP first.
 * For quick testing, HFP typically uses channel 1 or 3 — check with:
 *   sdptool browse 00:1A:7D:DA:71:11
 */
#include <stdio.h>
#include <string.h>
#include <unistd.h>
#include <sys/socket.h>
#include <bluetooth/bluetooth.h>
#include <bluetooth/rfcomm.h>

#define REMOTE_ADDR     "00:1A:7D:DA:71:11"   /* replace with your device */
#define RFCOMM_CHANNEL  1                       /* HFP channel from SDP */

static int send_at(int fd, const char *cmd) {
    char buf[256];
    /* AT commands in HFP end with carriage return */
    int n = snprintf(buf, sizeof(buf), "%s\r", cmd);
    write(fd, buf, n);
    printf("Sent:     %s\n", cmd);

    /* Read response — simple blocking read for demo */
    memset(buf, 0, sizeof(buf));
    int len = read(fd, buf, sizeof(buf) - 1);
    if (len > 0) printf("Received: %s\n", buf);
    return len;
}

int main() {
    struct sockaddr_rc addr = {0};
    int sock;

    sock = socket(AF_BLUETOOTH, SOCK_STREAM, BTPROTO_RFCOMM);

    addr.rc_family  = AF_BLUETOOTH;
    addr.rc_channel = RFCOMM_CHANNEL;
    str2ba(REMOTE_ADDR, &addr.rc_bdaddr);

    printf("Connecting to %s channel %d ...\n", REMOTE_ADDR, RFCOMM_CHANNEL);
    if (connect(sock, (struct sockaddr *)&addr, sizeof(addr)) < 0) {
        perror("connect failed");
        return 1;
    }
    printf("Connected. Starting HFP handshake.\n\n");

    /* HFP connection setup sequence (HF side) */
    send_at(sock, "AT+BRSF=20");     /* HF supported features bitmask    */
    send_at(sock, "AT+CIND=?");      /* query supported indicators        */
    send_at(sock, "AT+CIND?");       /* get current indicator values      */
    send_at(sock, "AT+CMER=3,0,0,1");/* enable indicator reporting        */
    send_at(sock, "AT+CHLD=?");      /* query 3-way call support          */

    printf("\nHFP Service Level Connection established.\n");
    printf("Now waiting for calls — press Ctrl+C to exit.\n");

    /* Read unsolicited AT notifications in a loop */
    char buf[256];
    while (1) {
        memset(buf, 0, sizeof(buf));
        int n = read(sock, buf, sizeof(buf) - 1);
        if (n <= 0) break;
        printf("AG says: %s", buf);

        /* If AG rings, automatically answer */
        if (strstr(buf, "RING")) {
            sleep(2);
            send_at(sock, "ATA");   /* answer the call */
        }
    }

    close(sock);
    return 0;
}

Find HFP RFCOMM Channel via SDP

# Find the RFCOMM channel number registered for HFP service on a device
sdptool browse 00:1A:7D:DA:71:11

# Look for output like:
# Service Name: Handsfree
# Protocol Descriptor List:
#   "L2CAP" (0x0100)
#   "RFCOMM" (0x0003)
#     Channel: 3          <-- this is the channel number to use

# You can also filter directly:
sdptool search --bdaddr 00:1A:7D:DA:71:11 HANDSFREE

GOEP is the base profile that defines how two Bluetooth devices exchange objects — files, contacts, calendar entries, notes, or any binary data. It is not a complete application by itself; instead it is the foundation that other profiles like OPP (Object Push Profile) and FTP (File Transfer Profile) are built on top of.

The protocol GOEP uses for actual data exchange is OBEX (Object Exchange), which runs over RFCOMM, which runs over L2CAP. OBEX itself was borrowed from IrDA (infrared) — the same protocol that older Palm devices used to beam contacts to each other.

OBEX uses a request-response model similar to HTTP. The client sends a request (CONNECT, PUT, GET, SETPATH, DISCONNECT) and the server responds with a status code (Success, Continue, Unauthorized, Not Found, etc.).

On Linux, OBEX/GOEP is handled by obexd — a standalone daemon that ships with BlueZ. It exposes the org.bluez.obex D-Bus interface for both client and server operations.

Push a File Using obexctl (OPP)

# Start obexd if not already running
sudo systemctl start obex   # or: /usr/lib/bluetooth/obexd -n &

# Use obexctl to push a file to a remote device
obexctl
[obex]# connect 00:1A:7D:DA:71:11
[00:1A:7D:DA:71:11]# send /home/user/photo.jpg
[00:1A:7D:DA:71:11]# disconnect

# Or send a vCard (contact) via OPP
obexctl
[obex]# connect 00:1A:7D:DA:71:11
[00:1A:7D:DA:71:11]# send /home/user/contact.vcf

Push a File via D-Bus in C

/*
 * obex_push.c — Push a file to a remote device using obexd D-Bus API
 * Compile: gcc obex_push.c -o obex_push `pkg-config --cflags --libs gio-2.0`
 * Run:     ./obex_push 00:1A:7D:DA:71:11 /home/user/photo.jpg
 *
 * This calls org.bluez.obex.Client1.SendFile() which is the standard
 * OPP (Object Push Profile) push operation.
 */
#include <gio/gio.h>
#include <stdio.h>

int main(int argc, char *argv[]) {
    if (argc < 3) {
        fprintf(stderr, "Usage: %s <bdaddr> <filepath>\n", argv[0]);
        return 1;
    }

    const char *bdaddr   = argv[1];  /* e.g. "00:1A:7D:DA:71:11" */
    const char *filepath = argv[2];  /* e.g. "/home/user/photo.jpg" */

    GError   *error = NULL;
    GDBusConnection *conn = g_bus_get_sync(G_BUS_TYPE_SESSION, NULL, &error);
    if (!conn) {
        fprintf(stderr, "D-Bus connection failed: %s\n", error->message);
        return 1;
    }

    /* Call org.bluez.obex.Client1.CreateSession to open OBEX session */
    GVariantBuilder *b = g_variant_builder_new(G_VARIANT_TYPE("a{sv}"));
    g_variant_builder_add(b, "{sv}", "Target",
                          g_variant_new_string("opp"));  /* OPP profile */

    GVariant *session_result = g_dbus_connection_call_sync(
        conn,
        "org.bluez.obex",              /* D-Bus name of obexd */
        "/org/bluez/obex",             /* object path */
        "org.bluez.obex.Client1",      /* interface */
        "CreateSession",               /* method */
        g_variant_new("(sa{sv})", bdaddr, b),
        G_VARIANT_TYPE("(o)"),
        G_DBUS_CALL_FLAGS_NONE,
        -1, NULL, &error
    );

    if (!session_result) {
        fprintf(stderr, "CreateSession failed: %s\n", error->message);
        return 1;
    }

    const char *session_path;
    g_variant_get(session_result, "(&o)", &session_path);
    printf("OBEX session opened: %s\n", session_path);

    /* Call org.bluez.obex.ObjectPush1.SendFile on the session */
    GVariant *push_result = g_dbus_connection_call_sync(
        conn,
        "org.bluez.obex",
        session_path,
        "org.bluez.obex.ObjectPush1",  /* OPP interface */
        "SendFile",                    /* push the file */
        g_variant_new("(s)", filepath),
        G_VARIANT_TYPE("(o)"),
        G_DBUS_CALL_FLAGS_NONE,
        -1, NULL, &error
    );

    if (!push_result) {
        fprintf(stderr, "SendFile failed: %s\n", error->message);
    } else {
        printf("File push started: %s\n", filepath);
        g_variant_unref(push_result);
    }

    g_variant_unref(session_result);
    g_variant_builder_unref(b);
    g_object_unref(conn);
    return 0;
}

Receive Files — Start OBEX Server

# Start obexd in server mode — auto-accept incoming file pushes
# Files are saved to /tmp/obex by default
/usr/lib/bluetooth/obexd --auto-accept --root /tmp/obex &

# Or for interactive accept/reject, just start obexd normally
# and use bluetoothctl / obexctl to manage incoming transfers

# Check what the OBEX server SDP record looks like:
sdptool browse local | grep -A 10 "OBEX Object Push"
